HI6222-02 pH/ORP/ISE Benchtop Meter Starter Kit
Set yourself up for testing success with our pH/ORP/ISE Benchtop Meter Starter Kit (HI6222). Our high-performing benchtop meter is ready-to-use straight out of the box and is fully equipped with everything you need to test. Includes necessary modules, electrodes, solutions, and more.
- Precise and consistent. Achieve quick, accurate, and repeatable results
- Reliable and efficient. Ensure quality and meet requirements with easy digital record keeping and increased traceability
- Simple and straightforward. Intuitive navigation menus, built-in help guides, and video tutorials make testing hassle-free
Fits seamlessly into any laboratory or industry environment.
Perfect for chemists, researchers, educators, food manufacturers, beverage producers, and metal finishers to name a few.
HI6222-02 pH/ORP/ISE Benchtop Meter Starter Kit
HI6222-02 (EU power plug) is supplied with HI6000 housing unit; HI6000-2 pH/ORP/ISE hardware module ×2 (installed); HI1131B pH electrode; HI7662-TW temperature probe; pH 4.01 buffer solution, 2 sachets; pH 7.01 buffer solution, 4 sachets; pH 10.01 buffer solution, 2 sachets; electrode cleaning solution, 2 sachets; pH & ORP electrode storage solution (25 mL); 3.5M KCl electrolyte solution (30 mL); capillary pipette, 1 piece; electrode holder with base plate, screw, cable holder clip (requires mounting); 24 VDC power adapter; USB-C to USB-A cable; meter quick reference guide; hardware modules quick reference guide and quality certificates; probes and meter quality certificates.
| Specification Name | Detail |
|---|---|
| Sku | HI6222-02 |
| pH Range | −2.0 to 20.0 pH; −2.00 to 20.00 pH; −2.000 to 20.000 pH |
| pH Resolution | 0.1 pH; 0.01 pH; 0.001 pH |
| pH Accuracy | ±0.1 pH; ±0.01 pH; ±0.002 pH (±1 last significant digit) |
| Calibration Points | Up to 5 |
| Calibration Type | Automatic; Semiautomatic; Manual |
| Standard Buffers | Hanna and NIST (pH 1.68, 3.00, 4.01, 6.86, 7.01, 9.18, 10.01, 12.45) |
| Custom Buffers | Up to 5 |
| Custom Group | Option to select from eight standard buffers and user-defined custom buffers |
| First Calibration Point | Offset or Point (user setting) |
| Isopotential Point | −2.000 to 20.000 pH |
| mV Range | −2000.0 to 2000.0 mV |
| mV Resolution | 1 mV; 0.1 mV |
| mV Accuracy | ±0.2 mV ±1 last significant digit |
| mV Calibration | Single point offset, ±2000.0 mV |
| ISE Range | 1.0×10¯5 to 300.0 ppt (g/L or mg/mL) 5.0×10¯3 to 1.0×105 ppm (mg/L or µg/mL) 1.0 to 5.0×107 ppb (µg/L) 1.0×10¯7 to 10.0 M (mol/L) 1.0×10¯4 to 1.0×104 mmol/L 1.0×10¯6 to 60.0 %w/v 5.0×10¯7 to 5.0×107 user |
| ISE Resolution | 1, 2, 3 significant digits |
| ISE Accuracy | ±0.5% (monovalent ions); ±1% (divalent ions) |
| ISE Calibration Points | Up to 5 |
| ISE Calibration Type | All Standards; Standard Group |
| ISE Standards | 7 standard solutions available for each concentration unit |
| ISE Custom Standards | Up to 5 |
| ISE Custom Group | Up to 5 |
| Temperature Range | −20.0 to 120.0 °C; −4.0 to 248.0 °F; 253.2 to 393.2 K |
| Temperature Resolution | 0.1 °C; 0.1 °F; 0.1 K |
| Temperature Accuracy | ±0.2 °C; ±0.4 °F; ±0.2 K |
| Temperature Calibration | Single point, adjustable |
| Temperature Compensation | Automatic; Manual |
| Reading Mode | Direct Direct/Autohold ISE Only: Known Addition, Known Subtraction, Analyte Addition, Analyte Subtraction |
| Basic View | Measurement data; Measurement profile (if enabled); Stability status |
| Simple GLP View | Basic view information; Last calibration date, slope, offset (pH, Rel. mV – ISE only) |
| Full GLP View | Simple GLP information; Calibration point details (pH & ISE) |
| Graph View | Basic view information; Measurement versus time graph |
| Table View | Basic view information, Table with measurements updated every second |
| Reading Stability Criteria | Accurate; Medium; Fast |
| Reading Sampling Rate | 1000 ms |
| Logging Type | Automatic; Manual; Autohold |
| Logging Number of Records | 50,000 maximum per file and stores at least 1,000,000 data points per user |
| Logging Automatic Interval | 1, 2, 5, 10, 30 seconds and 1, 2, 5, 10, 15, 30, 60, 120, 150, 180 minutes |
| Logging Sample ID | Incremental Mode; Manual |
| Logging Export Option | .CSV file format |
| Connectivity USB-A | 2 ports keyboard and/or printer input USB Flash Drive |
| Connectivity USB-C | 1 port PC Connectivity and USB-C Type Flash Drive |
| Connectivity Wi-Fi & Ethernet | FTP; Web Server (Log transfer and download); Email |
| Connectivity RS232 | Connecting peripherals |
| Calibration Reminder | Daily (0 minutes to 23 hours and 59 minutes); Periodic (1 minute to 30 Days, 23 hours and 59 minutes); or Disabled |
| Users | Up to 9 users and the default administrator account |
| Power Supply | DC adapter 100-240 VAC to 24 VDC 2A |
| Environment | 0 to 50 °C / 32 to 122 °F / 273 to 323 K maximum 95 % RH non-condensing |
| Dimensions | 205 x 160 x 77 mm (8.0 x 6.2 x 3.0 “) |
| Weight | 8.05 lbs |
