BL20 Black Stone Dosing Pump 18.3 lph 0.5 bar

Specification :
Max Output see above chart
Rated
Pressure
BL 20 0.5 bar (7.4 psi)
BL 15 1 bar (14.5 psi)
BL 10 3 bar (43.5 psi)
BL 7 3 bar (43.5 psi)
BL 5 7 bar (101.5 psi)
BL 3 8 bar (116 psi)
BL 1.5 13 bar (188.5 psi)
Dosing
Frequency 120 strokes/min
Pump Casing fiber-reinforced polypropylene
Materials pumphead in PVDF, diaphragm in PTFE,
glass ball valves and O-rings in FPM/FKM,
polyethylene 5 x 8 mm tubing
Self-priming max height: 1.5 m (5 feet)
Power Supply 110/115 VAC or 220/240 VAC, 50/60Hz
Max Power
Consumption approximately 200 W
Protection IP65
Environment 0 to 50°C (32 to 122°F); RH max 95% non-condensing
Dimensions 194 x 165 x 121 mm (7.6 x 6.5 x 4.8’’)
Weight approx. 3 kg (6.6 lb.)
